Gongzheng Apsaras G5 Max
Ultimate Superwide 3.2m Sublimation Solution | 8× Epson I3200 A1 | 403 m²/hr at 360×1200 dpi | Dual IR Dryer | 5-Litre Inks | Fashion / Home Textiles / Sportswear
OVERVIEW
The GongZheng Apsaras G5 Max is the ultimate superwide 3.2-metre sublimation transfer printer — the most capable model in the entire Apsaras range. While sharing the G5’s 8 × Epson I3200 A1 head count and 3.2 m print width, the G5 Max delivers 403 m²/hr at 360 × 1200 dpi resolution in draft mode — exceeding the G5’s 363 m²/hr at lower 720 × 600 dpi. A dual IR dryer system (2 × 27A), 13A printer power, 1,294 kg net weight, and a tighter working environment (23–29°C / 50–80% humidity) speak to the G5 Max’s industrial-grade engineering for sustained, climate-controlled production environments at peak throughput.
- TECHNICAL SPECIFICATIONS
- WHY CHOOSE Gongzheng Apsaras G5 Max?
| Model | Apsaras G5 Max |
| Print Heads | 8 × Epson I3200 A1 — staggered configuration |
| Ink Type | GS High Density Sublimation Transfer Ink — OEKO-TEX® ECO PASSPORT certified |
| Color Configuration | K.C.Y.M. (standard) Optional 8-color: K.C.Y.M. + S1.S2.S3.S4 |
| Ink Supply System | 5-Litre Bulk Ink Supply System with Ink Cartridges |
| Printing Width | Up to 3,200 mm (3.2 m) |
| Media Type | Transfer Paper (45 to 80 gsm) |
| Print Speed — Draft | 360 × 1200 dpi 403 m²/hr |
| Print Speed — Production | 360 × 1200 dpi 320 m²/hr |
| Print Speed — High-Res | 720 × 1200 dpi 210 m²/hr |
| Print Speed — Photo | 720 × 1200 dpi 165 m²/hr |
| Drying System | Dual Intelligent Sectionable Control IR Dryer (2×27A) |
| Feeder | Feeding: 1,000 m Taking up: 500 m |
| Roll Diameter | Up to 350 mm |
| Data Interface | External: USB 3.0 Internal: Fiber Optical |
| Software | neoStampa Delta / Ergosoft + GZ Printer Manager |
| Working Environment | Temperature: 23°C–29°C Humidity: 50%–80% |
| Power | Single Phase, 50Hz/AC, 220V±10%, 13A (Printer) + 2×27A (Dual IR Dryer) |
| Packed Size (L×W×H) | 5130 × 1300 × 1930 mm |
| Installed Size (L×W×H) | 4956 × 1466 × 1850 mm |
| Gross Weight / Net Weight | 1,734 kg / 1,294 kg |
Description
Print Quality — Uncompromised at Maximum Speed
- 8 × staggered Epson I3200 A1 printheads for unparalleled productivity at 3.2 m superwide scale
- GZ Variable Dot Technology — flawless skin tones, smoother gradients, crisp text and intricate detail at full production speed
- All draft/production modes run at 360 × 1200 dpi — higher than G5’s 720 × 600 dpi draft modes
- Standard K.C.Y.M. 4-color configuration optimal for all sublimation applications
- Optional 8-color K.C.Y.M. + S1.S2.S3.S4 for extended gamut and spot color accuracy
- Software: neoStampa Delta / Ergosoft + GZ Printer Manager for professional RIP and color management
- Self-developed Auto Capping Station with slant-wiper — saves maintenance time and extends printhead life
Industrial Media System — Superwide Production
- Confirmed 3200 mm (3.2 m) print width — full-width home textile fabric, curtain fabric, wide fashion cloth in a single pass
- Industrial Media Handle System with unique stretchable rubber bar for precise unwinding and rewinding
- Designed for low-gram (45 gsm) to heavy (80 gsm) transfer paper — transfer paper compatibility: 45 to 80 gsm
- Feeding: 1,000 m; Taking up: 500 m — matched to G5 Max’s dual-dryer high-speed production rhythm
- Roll diameter up to 350 mm — handles large jumbo rolls for sustained production
- Grooving Anti-Wrinkle Platen — pressure-adjustable pinch rollers for wrinkle-free feeding on dark-color papers
- Data interface: External USB 3.0 + Internal Fiber Optical — fast data transfer for superwide high-resolution files
Sustainable & Certified
- GS High Density Sublimation Transfer Ink certified by OEKO-TEX® ECO PASSPORT
- Meets stringent human health and environmental safety criteria for premium textile supply chains
- Water-based sublimation inks — no harmful solvents
- Essential for premium fashion, home textiles, and sportswear brand supply chain compliance
