Gongzheng Apsaras G4
1.9m High-Volume Sublimation Printer | 4× Epson I3200 A1 Heads | Up to 185 m²/hr | 8-Color Option | Heavy-Duty Industrial Feeder | Sportswear / Fashion / Home Textiles
OVERVIEW
The GongZheng Apsaras G4 is a high-volume 1.9-metre dye-sublimation transfer paper printer built for print service providers, textile manufacturers, and fashion producers demanding industrial-scale throughput. Powered by 4× staggered Epson I3200 A1 printheads — double the head count of the Apsaras G2 — it delivers up to 185 m²/hr in draft mode and supports an optional 8-color configuration (KCYM + S1.S2.S3.S4) for wider color gamut and spot color accuracy. The Heavy-Duty Media System with rear-position design, 3-liter bulk ink tanks, 1,000 m feed, and Intelligent Sectionable Control IR Dryer enables long unattended production runs on transfer papers from 35 to 100 gsm.
- TECHNICAL SPECIFICATIONS
- WHY CHOOSE Gongzheng Apsaras G4?
| Model | Apsaras G4 |
| Print Heads | 4 × Epson I3200 A1 — staggered configuration |
| Ink Type | GS High Density Sublimation Transfer Ink — OEKO-TEX® ECO PASSPORT certified |
| Color Configuration | K.C.Y.M. (standard) Optional 8-Color: K.C.Y.M. + S1.S2.S3.S4 |
| Ink Supply System | 3-Litre Bulk Ink Supply System with Ink Tanks |
| Printing Width | Up to 1,950 mm (1.9 m) |
| Media Type | Transfer Paper (35 to 100 gsm) |
| Print Speed — Draft | 360 × 1200 dpi 185 m²/hr |
| Print Speed — Production | 360 × 1200 dpi 165 m²/hr |
| Print Speed — High-Res | 720 × 1200 dpi 102 m²/hr |
| Print Speed — Photo | 720 × 1200 dpi 88 m²/hr |
| Drying System | Intelligent Sectionable Control IR Dryer |
| Feeder | Feeding: 1,000 m Taking up: 500 m |
| Roll Diameter | Up to 300 mm |
| Data Interface | External: Ethernet Internal: Fiber Optical |
| Software | neoStampa Delta / Ergosoft + GZ Printer Manager |
| Working Environment | Temperature: 18°C–30°C Humidity: 35%–65% |
| Power | Single Phase, 50Hz/AC, 220V±10%, 6A (Printer) + 27A (IR Dryer) |
| Packed Size (L×W×H) | 3570 × 1040 × 1820 mm |
| Installed Size (L×W×H) | 3391 × 1192 × 1730 mm |
| Gross Weight / Net Weight | 752 kg / 542 kg |
Description
Print Quality & Color — Industry-Leading Output
- 4× staggered Epson I3200 A1 printheads — unparalleled productivity and high print quality for high-volume sublimation production
- GZ Variable Dot Technology — flawless skin tones, smoother gradients, crisp text and intricate detail at full production speed
- Standard KCYM 4-color configuration — optimal for standard sublimation applications
- Optional 8-color configuration: K.C.Y.M. + S1.S2.S3.S4 — wider color gamut for premium fashion, sportswear and branding applications
- All print modes run at 1200 dpi resolution (360 × 1200 draft/production, 720 × 1200 High-Res/Photo) for consistent sublimation quality
- Software: neoStampa Delta / Ergosoft + GZ Printer Manager for professional color management and RIP
Industrial Media Handling — Built for Volume
- Heavy-Duty Media System — rear-position design ensures precise handling of large paper rolls with sufficient drying time
- Feeding: 1,000 m; Taking up: 500 m — designed for extended unattended production runs
- Roll diameter up to 300 mm — handles large paper rolls for sustained industrial throughput
- Transfer paper compatibility: 35 to 100 gsm — covers the full range from lightweight fashion to heavy banner-weight transfer stock
- Grooving Anti-Wrinkle Platen — pressure-adjustable pinch rollers with grooving platen and post-spreading roller for wrinkle-free feeding
- Especially effective on dark-color transfer papers where wrinkle prevention is critical
Big Volume Ink & Unattended Production
- 3-litre bulk ink tanks per channel — big volume output, easy maintenance, long-time unattended operation
- Significantly lower ink changeover frequency vs. standard cartridge systems — ideal for 24-hour production environments
- Auto Capping & Wiping System — maintains printhead health, ensures excellent print quality and sustained productivity
- Intelligent Sectionable Control IR Dryer — efficient and uniform drying across the full 1.9 m print width
- Data interface: External Ethernet + Internal Fiber Optical — fast, reliable data transfer for high-resolution files
- Single-phase power — 220V±10%, 6A (Printer) + 27A (IR Dryer)
Sustainable & Safe for Textile Supply Chains
- GS High Density Sublimation Transfer Ink certified by OEKO-TEX® ECO PASSPORT
- OEKO-TEX® ECO PASSPORT ensures inks meet stringent criteria for human health and environmental safety throughout the textile supply chain
- Suitable for tier-2 and tier-3 production partnerships with global sportswear and fashion brands requiring certified sustainable production
- Water-based sublimation inks — no harmful solvents
